Discontinued

echo™ 551c

Part Number 010-01262-00

ONLINE STORE

Feature
Specs
In The Box
Update
Accessories
Compatible Devices

A Powerfully Simple Hi-Res 5-inch Color Fishfinder

Exclusive advanced HD-ID™ sonar with or without a transducer (depending on version)
High-resolution 5-inch diagonal VGA color display
Transmit power (RMS)/(Peak-To-Peak): 500 W/4,000 W
Frequency: 77/200 kHz included (supports 50/200 kHz)
Quick-release tilt/swivel mount and transom/trolling motor transducer and mounts included

The color echo 551c is a premier fishfinder with one of the brightest 5-inch high-resolution VGA color displays on the water. Its built-in advanced HD-ID sonar with or without a 77/200 kHz transducer (supports 50/200 kHz transducer, sold separately) offers extra sharp resolution and detail on fish, structure and bottom returns with the power to scan to a 2,300-foot maximum¹ depth.

With its simple, streamlined interface with 4,000 W peak-to-peak power, the echo 551c has wide viewing cone angles (60/120 degrees) optimized for targeting fish beyond the sides of your boat in deep or shallow water – in addition to Smooth Scaling™ depth-range adjustments and sonar history rewind.

Mount and Go

Ready-to-go with a quick-release tilt/swivel mount and transom/trolling transducer mount kit, so you can get right to fishing.

¹Maximum depth dependent on transducer, water, salinity, bottom type and other water conditions.

Physical & Performance
Physical dimensions	6.0" x 5.9" x 1.8" (15.2 x 15.0 x 4.6 cm)
Display size, WxH	2.9” x 4.0” (7.4 x 10.16 cm); 5” diag, (12.7 cm)
Display resolution, WxH	480 x 640 pixels
Display type	VGA color
Weight	17.6 oz (499 g)
Water rating	IPX7

Features & Benefits
Audible alarms
Dual-frequency (50/200 kHz) sonar capable
Dual-beam (77/200 kHz) sonar capable
Split-screen zoom
Ultrascroll^® (displays fish targets at higher boat speeds)
Fish Symbol ID (helps identify fish targets)
AutoGain Technology (minimizes clutter, maximizes targets)
Whiteline (indicates hard or soft bottom)
Adjustable depth line (measures depth of underwater objects)
A-scope (real time display of fish passing through transducer beam)
Bottom lock (shows return from the bottom up)
Water temperature log and graph
Water temperature sensor included
Water speed capable (displays speed on water)

Other Specs
Frequencies supported	50/77/200 kHz
Transmit power	500 W (RMS)/4,000 W (peak to peak)
Voltage range	10-28 Vdc input
Maximum depth	2300 ft @ 77 kHz, freshwater
Cone angle	60º or 120º (dual beam)
Additional	HD-ID Tracking Technology Sonar History Rewind

echo 551c
Quick release mount with tilt and swivel
Power cable
Transducer w/ mounting bracket, hardware and trolling motor clamp
Documentation
