Lumishore LUX SNL180

Part Number 010-04410-00

ONLINE STORE

Feature
Specs
In The Box
Update
Accessories

FLEXIBLE, FULL-COLOR DOT-FREE MARINE LIGHTING

Bring seamless, dot-free lighting on board with these flexible, high-density neon-style LEDs. Their bend-flex design hugs curved surfaces — perfect for gunwales, cabin headliners and T-tops.

FULL-COLOR CRGBW LIGHTING

60 CRGBW PER METER

PLUG-AND-PLAY INSTALLATION

CONTROL VIA COMPATIBLE MFD, LUMISHORE DISPLAY, SMART DEVICE OR MOMENTARY SWITCH¹

IP67-RATED FOR DUST AND WATER PROTECTION

3-YEAR WARRANTY

¹The momentary switch control requires the Strip Driver; the MFD, Lumishore display and smart device control require the EOS-LUX Command Center

General
Warranty	3 years
LED colors	CRGBW, Full Spectrum RGB and Tuneable White (2700 K to 6500 K) in the same fixture
LED type	60 CRGBW/m
Length of strip per strip driver	up to 10 m total
Electrical installation	Plug and play
Operating voltage	10.5-31 VDC (via LUX Control Module)
Current consumption 12 V (max)	0.6 A/m (via Strip Driver)
Current consumption 24 V (max)	0.36 A/m (via Strip Driver)
Average power draw	8.7 W/m
Construction	Fully encapsulated and potted with spot-free diffuser
Water and dust rating	IP67
Control Options
Momentary switch	yes (via Strip Driver)
EOS-LUX Command Center
Compatible MFD	yes (via EOS-LUX Command Center)
Smart device	yes (via EOS-LUX Command Center)
EOS-LUX-SUPRA Display	yes (via EOS-LUX Command Center)
Mounting Dimensions
Dimensions (depth)	0.83" (21 mm)
Dimensions (height)	0.56" (14.15 mm)
Mechanical installation	Stainless steel screw clips (supplied)

LUX SNL180 strip light (based on selection)
Pack of fixing clips
